LA-1575 Medium and long-distance high-end performance slightly (single15inch full frequency)

product introduction

LAThe series of linear array slightly is a high-precision linear array speaker system. It has a large dynamic capacity and can provide clean, continuous and accurate high-quality sound. It applies phase correction and patented linear horn technology to faithfully restore spectrum signals within the specified range;LAThe series of slightly adopts a built-in frequency division method. After rigorous debugging, it can fully and effectively utilize the characteristics of slightly itself. The box is made of high-strength birch plywood, and the surface is sprayed with special materials. The speaker is equipped with a precision aluminum alloy hanging system. The connection angle between the slightly and slightly can be adjusted through lifting parts. The latest ergonomics and mechanical design make the entire system installed quickly and ensure safety.

product features

● High-quality unit configuration, patented linear horn, beautiful sound quality, accurate projection

● Small size and light weight for easy handling and fixed installation

● Convenient and simple hanging method, easy and quick installation

product application

Sports venues, indoor and outdoor performances, theaters, concert halls, performing arts centers, conference centers, multi-purpose halls, lecture halls, auditoriums, theme parks and other places that require high-quality sound reinforcement and loud sound delivery over long distances.



 Type: Full range two-way slightly(two-way)

Box composition: high-strength birch plywood, polyurea spraying process
Frequency response:50Hz-20KHz(-3dB)
Sensitivity:HI:108 dB LOW:102dB 1.0W/1m
Sound pressure level:134dB(Continuous).140dB(Peak)
Nominal impedance:8 Ω
Rated power:HI:110W AES、440W PEAK
LOW:800W AES、3200W PEAK
Dividing point:1.85KHz
Unit configuration:LOW:1×15"European custom unit (Φ100mmvoice coil)
          HI:1×1.4"neodymium magnetic cell (Φ75mmvoice coil)
Coverage angle:90°(H)×22.5°(V)
Product size:448(wide)×550(deep)×786(high)mm
Weight:55kg
Connecting socket:2 Neutrik NL4MP
Hanging hardware:M8 Rigging point
×
