Digital audio physical interface:2roadRJ45（PRIMARY、SECONDARY）
Digital audio transmission channel:32×32channelDANTENetwork audio signal
Expansion card passesDante controllerSoftware distribution matrix routing switching, seamless connection with digital mixing consoles through plug-in card type can be combined with otherDANTEEquipment (e.g. beltDANTEaudio matrix processor for transmission protocol,DANTENetwork slightly, etc.) is based on the digital mixer operating platform and connected through network cables to form a digital system for two-way transmission and distribution of network audio. Digital mixing consoles have specialDigitalSet the buttons through the touch screen of the mixerDANTE NETWORK AUDIO lower layerDIGITAL INPUTDigital signal input operation interface can be easily set from otherDANTEDigital signal input to the device; simultaneouslyDIGITAL OUTPUTThe digital signal output operation interface can also easily connect the mixer32Channel digital signals pass throughCT1804DANTEEquipment required for expansion card output to the remote end (such as tapeDANTEaudio matrix processor for transmission protocol,DANTEInternet slightly, etc.).
frequency response range:20-20kHz±0.2dB
Ethernet transmission:ACT/LINK 1G-T Maximum network cable transmission100meters
Ethernet connection port:ACT/LINK 1G-T RJ45port
Channel structure:32×32channelDANTENetwork audio signal
Control software:Dante controller
Indicator light:RJ45network portLED
Product size:122(wide)×108(deep)×33(high)mm
Weight:0.15kg
