Product features:
12a muteDCA grouping control,Achieve group control and simplify operations;
1/4"TRS Headphone output with proprietary control;
The machine comes with it13a1inch colorOLEDChannel signal display screen can display the number of channels, edited channel names, volume values and other information. Channel names can be edited through the touch screen;
26Each belt working blue light physical adjustment knob, among which24input channels0dB-50dBGain adjustment (withSIGCLIPlights),1Each control room monitors the volume adjustment,1Monitor volume adjustment through headphones;
2Each parameter editing knob with working green light, among which1Each is a multifunctional combination of parameter adjustment,1One is sound image adjustment;
input processing——Preamplifier (with physical knob adjustment), digital high-pass filter, digital noise gate, digital full-parameter adjustment parametric equalizer, Digital compressor, digital delay, phase, audio-visual and other digital processing;
Mixing output processing——Digital full parameter adjustment parametric equalizer, digital31Segment graphic equalizer, digital compressor, delay, phase, audio-visual and other digital processing;
Fast copying of channel parameters/paste/Reset parameters, program, save, load and copy functions;
With channel parameters, channel volume, effect editing, channel dispatch, auxiliary effect dispatch,48VPhantom power supply, digital signal input and output, automatic mixing, sound field analyzer,31Quick operation light-emitting buttons for adjusting functional parameters such as segment icon equalization, monitor clearing, mute clearing, and stereo link;
Proprietary physical control button knobs are used for channel processing (gain, high-pass filter, noise gate, compressor, audio image, parametric equalizer, phantom power supply, digital signal input and output, automatic mixing);
The machine comes with it2Group digital effects, each group has12Choose from various effects, and adjust multiple parameters, each group of effects can be saved104Effect scenes;
device hasUSBDigital audio input output port(Connected to computer direct digital signal input to mixer2324Path, output defaultLRmain output)
Input channels can be connected into stereo pairs (LINK), easy to operate control;
device supportstalkbackStage intercom function, the touch control interface has a special intercom control interface;
User rights settings, and the machine operation interface has rights operation functions such as locking, unlocking, and changing password;
Device has network,USBConnect remote control port, which can be usedIPADapplicationAPPProgram wireless control;
Built-in automatic microphone mixing (AUTOMIX) Function;
built-in31 Segment audio real-time analyzer (RTA), which can analyze the audio of any input and output signal;
Each path has independently controlledDC48VPhantom power supply;
Technical parameters:
Audio output:1groupXLRTRSbalance typeLRmain output
Auxiliary output:8roadXLRTRSbalance typeLRauxiliary output
USBInput and output:1roadUSBSquare port I/O
Control room output:TRSport
Headphone monitoring output:TRSport
Control port:1roadUSB、1roadETHERNETport
Work lighting:1roadUSB 5V -500mAinterface
Channel display:13block1inchOLEDcolor screen
Blue light control knob:24channel gain control knobs,1Control room volume knobs,11 headphone monitor volume knob
Green control knob:1apanaudio-visual control knob,1aParameter AdjustMultifunctional control knob
Silicone light control buttons:75a
Save scene:24Save scenes,48DSPSaving channel parameters,48aGEQparameter saving,104Save digital effect parameters
Frequency response:20Hz -20kHz at 0dBu ±1.5dB
Distortion (THD&N）：0.01% at 0dBu 1KHz
speech gain:0dBu ~50dBu
Signal to noise ratio:107dB
Maximum input level:+20dBu
Phantom power supply:+48VDC
Line input: unbalanced
System crosstalk:
Input to output (at +4dBu 1KHz ）：-88dBu
Adjacent channel crosstalk (at +4dBu 1KHz ）：-85dBu
Bottom noise:-88dBu
Noise door:
Threshold range:-84dB~20dB
Start time:0.5ms~200ms
Release time:10ms~1.0s
Compression:
Threshold range:-30dB ~ +20dB
Start time:10ms~150ms
Release time:10ms~1s
Compression ratio:1：1 to 10:1~Limit
Gain:0dBu ~ +24dB
Equalization:
Low frequency (low-pass-Qualcomm):20.6Hz~20KHz ±24dB
Low IF:20.6Hz~20KHz ±24dB
Medium and high frequency:20.6Hz~20KHz ±24dB
High frequency (low-pass-Qualcomm):20.6Hz~20KHz ±24dB
Digital audio:
Dynamic range of analog-to-digital conversion:114dB
Dynamic range of digital-to-analog conversion:114dB
Input processing:32-bit, floating point arithmetic
Analog to digital conversion, digital to analog conversion quantization depth:24bit
Impedance:
Microphone input impedance:6.8kΩ
Line input impedance:75k
Other output impedances:240Ω
Operating temperature range:0~40℃
Equipment storage temperature range:-20℃~ 45℃
Product size:540(wide)×525(deep)×200(high)mm
Weight:13kg
