32Each input channel,26gildedXLRand balanced6.3mmSingle sound input channel for socket; with20aDIRECTDirect output andINSERTInsertion point, main output and grouping output all haveINSERTInsertion point.6Each has6.3mmStereoscopic input channel for socket and level selector switch
Has main outputL/R, center positionC, four-way formation,6Auxiliary output channel
Level controlled4of binauralAUXloopback back and can send the signal toAUX1
Monaural input channel is attached to high-pass filter, cut off frequency point100Hz，18dB/Oct, each channel has an inverter device.
Gain adjustment and+48Vphantom power
Has intercom function and can send toL、R、Cand grouping and assisting1-2、3-4、5-6, control the management level through the knob
with two99This model digital effects device, and other processing modules can also be selected according to usage needs.
There is one on the mono input channel4sectionEQHigh school frequency sweep
Equipped with stereo input channel4segment is securedEQ
6aAUXoutput:AUX1-6With fader before/Later adapt to return;AUX5-6After the fader is used to send the effect
Each input channel hasMUTE/SUB1-2/SUB3-4/CENTER/LR，SOLOSwitches and signal indicationsLEDand overloadLED
Recorder input with disconnect switch/Output, which sends the signal to the control room and the main mix output.
hasUSBDigital signal port, used to play computer audio signals. At the same time, you can also connect to a computer through this port to record sound through recording software
has7×2Matrix output, any4groups, left channel, right channel, andCThe (mono) bus can be sent to the matrix via respective knob potentiometers2output terminal.
Matrix(MAIN MIX/1-2/3-4)and dispersed output levels for headphones/control room
balance typeXLRand6.3mmoutput seat
size:
Bare metal:980(wide)×520(deep)×35(Former high)×175(Later high)mm
Add wooden border strips:1025(wide)×520(deep)×40(Former high)×175(Later high)mm
Weight: bare metal:18.42kg; Add wooden border strips:19.56kg
