Product features:
6Group bus, a group of left and right channel main outputs,2Group output,PHONES+MONITORLRDual monitoring channel output;
3groupAUXAuxiliary output among themAUX1、2Can be selected as fader forward and fader output later AUX3forEFFEffect sending channel;
EFFECTThe effect bus has a separate output push rod and hasMUTEMute control switch,PELMonitor distribution switches,MIXmain output distribution switch,SUBgrouping output distribution switch;
Each microphone provides high-quality+48Vphantom power ;
Each input has three stages of equalization,whereinMIDIt has a frequency sweeping function, and the range of the frequency sweeping frequency band ranges from150Hzto3.5KHz ，HIHigh frequency center frequency is12KHz、LOWLow frequency center frequency is80Hz; Each input hasPANLocation and adjustment of left and right sound images;
Each input has green indicator light and red indicator light for peak signal;
Each input hasMUTEMute control switch button,MAINmain output distribution switch button,SUB1、2grouping output distribution switch buttons,SOLOsolo switch button;
The mixer has a built-in Bluetooth receiving module that can be wirelessly connected with Bluetooth devices to achieve wireless access of audio signals;
built-in24kindDSPDigital effects, with2.8Inch color screen display display effect types,EFFECTEffect main output with100MMTravel dust prevention and high-analysis fader control;
Main output and grouping specific12sectionLEDstereo monitor level meter ;
The circuit board adopts double-sidedSMTPatch technology makes performance stable and reliable ;
has17road100MMThe high-travel push rod is used to control the volume adjustment of the input and output channels (including input12Road, grouping2Road, effect1Path, main output2Road);
Technical parameters:
total harmonic distortion:-0.005%
frequency response:20Hz-20KHz+1dB /-3dB
maximum output level/Max output level：18dBm (1KHz, THD=0.5%)
SNR:-81dB
gain control/mono:51dB~0dB
stereo:-26dB~0dB
residual output noise:-83dBu
crosstalk:-79dBu
Headphones output power/Earphone output power：260mW(1KHz,THD=0.5%，200Ω)
equalizer:
low:80Hz±15dB
in:150Hz-3.5KHz
high:12KHz±15dB
input and output impedance:microphone input:2.4KΩ
monaural input:10KΩ
stereo input:100 KΩ
output impedance:75Ω
consume power:100W
Product size: Width:502mm*Deep:410mm*Gao:105mm(Former Gao),60mm(and then high)
Weight:6.8KG
