Audio pickup methods are available: handheld, head-mounted, and lavalier
single channelUHFUltra-high frequency wireless system, complete machine100frequency tunable
Adopt digital voice code locking technology to effectively block noise interference in the use environment
Adopt the latest infrared automatic frequency matching technology, making it easier to set and operate, and easier to use
Adopt true diversity receiving circuit design to ensure effective receiving distance and continuous transmission and eliminate dead spots
Receiver indicators:
Carrier frequency band:UHF 640～690MHz
Modulation method:FM
Oscillation mode:PLLphase-locked frequency synthesizer
Frequency stability:±0.0005%
Sensitivity: at offset equal to25KHz, enter6dBμVwhenS/N>60dB
Maximum offset:±45kHz
Band width:40MHz
comprehensiveS/NCompared to:108 dB
comprehensiveT.H.D.：0.4% @ 1 KHz
Comprehensive frequency response:65Hz~18kHz ± 3dB,
Maximum output voltage: Balanced type:-20dBV/100Ω,
Unbalanced formula:-4dBV/5KΩ.
Output socket:XLRbalanced and6.3φunbalanced socket
Effective working distance: General100Rice (open place)
Power supply:100 - 240V
size (width×deep×high):210×175×44mm
Weight:1.53kg
Transmitter technical specifications:
Harmonic radiation:-63dBm
Band width:20MHz
Maximum offset:± 45KHz
Power output:3 0mW
Frequency response:50Hz~18KHz
Maximum input sound pressure:130dB SPL
Sound head: capacitive type
Battery:AA×2
Current consumption:<110 mA
