TZCoaxial slightly
product introduction
TZCoaxial speakers areSONIC PRO®A new generation of point sound source technology products,TZThe series provides complete sound reinforcement technology to meet the high requirements of professional audio users.TZThe series of slightly also offers the best ultimate sound performance in terms of compact, versatile use. The main advantage of coaxial technology is that the radiation of a single point sound source has excellent phase response characteristics. The speaker has complete wavefront coherence and axisymmetric directionality at all frequencies, producing exactly the same horizontal and vertical coverage angles, forming a true "point sound source"; moreover, the coaxial design makes low frequencies/The high frequency has completely overlapping diffusion characteristics, which avoids the weakness of the typical polar lobe effect of the traditional combination of horn tweeters and low-frequency speaker units. The end result is naturally to bring studio-level monitoring sound quality, which is an ideal near-field monitoring., fully suitable for semi-reverberation environment applications.
TZThe coaxial speaker adopts a very flexible design method, which is suitable for both fixed installation and mobile performances. It is suitable for main sound reinforcement, sound filling or monitoring applications on the performance stage and is convenient for hoisting. The coaxial series speaker unit is the latest generation of products. It is a cutting-edge electronic acoustic engineering design. The interior of the coaxial speaker unit adopts a high-quality voice coil for high treble. It combines the latest composite material treble diaphragm and aluminum alloy brushed horn to bring excellent sound quality. Performance and enjoyment of hearing, the sound is natural, clear and more expressive.TZThe coaxial slightly is quick and easy to install, ensuring accuracy and safety, and fully complying with today's assembly safety standards.
product application
Theater, music bar, club, high-end businessKTV, gymnasium, church, multi-purpose hall, conference room, multi-purpose application, etc.
Type: Full range two-way coaxial slightly(two-way)
Frequency response:35Hz-20KHz(-3dB)
Sensitivity:106dB 1.0W/1m
Sound pressure level:130dB(Continuous).136dB(Peak)
Nominal impedance:8 Ω
Rated power:600W
Peak power:2400W
Coaxial unit:LOW：1×18"（Φ75mmvoice coil)
HI：1×1.4"（Φ75mmImported voice coil)
Coverage angle:90°(H)×90°(V)
size: front516, after349(wide)×521(deep)×697(high)mm
Weight:36.5kg
Connecting socket:2Neutrik NL4MP
Hanging hardware:M8 Rigging point
