Camera and discussion functions
Develop and design using all-digital high-fidelity circuits
The connection between the conference system host and the conference unit uses an eight-core dedicated signal line
The system host adopts LCD display, and the menu operation is intuitive and user-friendly
Single machine can realize conference functions: free speech mode, rotation mode, restricted mode, chairman mode
Hand in hand connection, the connection method is simple and the line is simple
support8Video switching input interface,21-channel video output interface,1Road computer data interface(RS-232), representative machine wiring base*4, microphone balanced output Cannon interface*1, mixed output interfaceLRinterface*2
High-speed cloud ball control interface supportRS-232/485Control Protocol
Select the number of microphones to speak at the same time1-9Branch (inclusive)
Built-in video interface, which can be connected to the image positioning and tracking CPU to realize speech positioning and tracking functions
has3Main cable terminals,1Expansion cable terminals that can be connected60Group conference unit with load and short circuit protection functions, which can be achieved by adding expansion equipment250Desk conference units are used simultaneously
You can directly select the type of text displayed and Chinese Simplified/Chinese Traditional/English
Has chairman mode selection function: you can select chairman exclusive/Chairman General
Automatic shutdown option: Optional automatic shutdown/no
Features chairman prompt tone selection function: you can select/no
with3Group audio signal output terminal, can be connected to external recording or audio equipment
Frequency response:20Hz-20KHz
Total harmonic distortion: in20Hz-20KHzConference system sound output is less than0.1%
usingAC220Vpower supply
can be installed in19inch standard cabinet
size:482(wide)×370(deep)mm×87(high)mm
Net weight:8.5kg
