Technology type: All digital high performanceUHFWireless conference system with camera tracking function in frequency band, built-in highly stable industrial-grade embedded processor;
Antenna interface:3A coaxial antenna interface,ANT-A、ANT-B、ANT-CThe three interfaces correspond respectively3Split antennas with different frequencies
Receiving distance:60Meters (depends on on-site radio environment)
Audio output:1a6.35mmMIX OUT,1aXLRCannon output
Vibration method:PLLphase-locked frequency synthesis
Sensitivity: at offset equal to25KHz,input6dBvwhenS/N>60dB
Band width:50MHz
Maximum offset:±45KHz
comprehensive signal-to-noise ratioS/N：105dB
comprehensiveT.H.D：0.7%@1KHz
Conference unit number: customizable
Number of supporting chairman units: unlimited
Number of units opened:1~4
Speech timing: Yes, reflected on the microphone screen
Video control method:RS-232、RS-485
Ball machine capacity:8Taiwan
Panel material: Advanced space gray aluminum alloy panel
Accessories:3root antenna,1power adapters
size (width*deep*high):482×272×95mm
Installation: Applicable19inch standard rack
Net weight:3.88KG
