product introduction
TBThe series of slightly positioned for meetings and multi-functional sound reinforcement. The sound is restored faithfully and smoothly; the tweeter unit uses imported voice coil and polymer polyester composite film, which provides exquisite sound performance and good transient response;Especially suitable for indoor sound reinforcement, it can faithfully restore voice and music sound reinforcement,TBThe series has rich hanging points and is designed at the bottom of the slightly—a35mmbracket hole base, the box body is composed of15mmIt is composed of high-density board, the surface is made of wear-resistant black dotted waterproof and environmentally friendly water-based paint, and the rear wiring board is connected in parallel.NL4MPThe core socket is easy to connect. The black internally covered acoustically transparent acoustic sponge and perforated iron mesh protect the slightly unit. The surface mesh is fixed with internal hexagonal plane screws. The overall appearance is beautiful and elegant.
product application
Conference rooms, multi-purpose halls, lecture halls, hotels, exhibition halls, churches, multi-purpose applications, etc.
Type: Full-range two-way slightly (two-way frequency)
Frequency response:55Hz-19KHz(-3dB)
Sensitivity:92dB 1.0W/1m
Sound pressure level:112dB(Continuous).118dB(Peak)
Impedance:8 Ω
Rated power:100W
Peak power:400W
Unit configuration: LOW:1×8"（Φ36mmvoice coil)
HI:1×1"（Φ25mmImported voice coil)
Dividing point:2.5KHz
Coverage angle:90°（H）×50°（V）
Product size:293(wide) ×250(deep) ×441(high) mm
Weight:9kg
Connecting socket:2 Neutrik NL4MP
Hanging hardware: M8 Rigging point
