Product features:
Real-time transmission of digital audio signals(Adopt through network cableDanteTransfer Protocol)
Point-to-point or point-to-multiple audio transmission
Analog signal input with multiple channel configurations/output
provide48Vphantom power
useCAT5Line realizes multiple connection methods, and transmission can be reached100Meters, exceed100Rice can be transmitted through optical fiber
Dedicated software configures channel routing
Technical parameters:
24bitQuantization, sampling frequency:48KHz/96KHz/192KHz
Dynamic range of analog-to-digital conversion:114dB
SNR of analog-to-digital conversion:105dB
Dynamic range of digital-to-analog conversion:120dB
Signal to noise ratio of digital-to-analog conversion:107dB
Gain adjustment:0dB-50dB
Maximum input level:20dBu
Channel delay:3ms
Total harmonic distortion: (1K Hz）:<0.005%
frequency response range:20-20kHz±0.5dB
Bottom noise:<-96dB0dB Gain
Adjacent channels:<-92dB0dB Gain
Ethernet transmission:100Base-T CAT-5cable largest100meters
Channel structure:16into16out interface
Input range:±25dBanalog channel
Ethernet connection port:CAT-5port
