AD-7.1  Cinema Decoding Processor (7.1decoding)

AD-7.1 Cinema Decoding Processor (7.1decoding)

  • Introduction
  • Parameter

 This is a fully functional one7.1Decoder, but also a top-class karaoke machineOKProcessor, multifunctional, perfect sound qualityK, movie bars, and cinemas are rare and excellent decoding processors. Fully automatic identificationDTS,DTS-HD,DOLBY,AC-3, truly7.1Channel decoding; Has industry-unique automatic reverberation effect (As long as you raise the reverb level, you can enjoy the effect of intelligent automatic adjustment of the reverb to follow your speed); Microphone excitation function, the improvement of low and high frequencies makes the sound thicker, dynamic and wider sound field; The full-frequency slightly has an ultra-low simulation effect enhancement function, which will greatly improve the listening sense of music; the built-in music level automatic gain function completely solves the problem of music suddenly being large and small, making all music sounds consistent, making it more comfortable for users to use; with AmericanADIThe company's latest top-notch processing chip; supports high-fidelity stereo audio transmission. There are three inputsHDMI, optical fiber and lotus input, you can freely switch modes;HDMIwith7.1Channel output, each channel has10The segment parameters are balanced, and each slightly can independently adjust the crossover point delay; the function, timbre, software and hardware indicators are the highest, and dynamic can be achieved120dB;ABThe two sets of microphones are separately debugged for equalization and effect, among which the microphone is balanced10Paragraph, balanced effect7Segment; with echo, reverberation7Segment parameter equalization function; Personalized setting function, which can limit the maximum volume and startup volume.


Technical parameters:
Signal to noise ratio: MIC 99dB、 MUSIC 99dB
total harmonic distortion+Noise:MIC 0.01% 、MUSIC 0.01%
maximum input levelMICTHD+N  0.1%、MUSIC 1.5Vrms THD+N  0.1%
Dynamic range:MIC 96dB THD+N 0.1%、MUSIC 100dB THD+N  0.1%
noiseMIC/MUSIC 35uVrms Noise door opens,MIC/MUSIC 150uVrms Noise door closed
Decoding:DOLBY、DTS
Input interface:MIC 2Road wired microphone 、MUSIC 1optical fiber input,3aHDMI、2Group Lotus (AUX)
Output interface:81 Cannon ports (main output, side surround, rear surround, center and ultra-low),1aHDMI(Video)
Balanced adjustment: EQ Input input Microphone independent10sectionx2, music10Segment, reverberation echo each7Duan,10sectionPEQx8Channel output (equalization type can be customized)
Power consumption: No load 5W, standby 2W
Screaming suppression function:FBC Built-in software frequency-shifted howling suppression
Machine size(wide×deep×high):485×200×61mm
Weight:2.14kg
×
