Product features:
a5.5inchRJ45The interface touch programmable control screen is mainly installed in the wall box, conference desktop, operating desk desktop, etc., and is widely used in conference rooms, multi-function halls, and report halls. Just need to work withMATRIXSeries digital audio matrix processorsRJ45The volume control of one or more digital audio matrix processors can be easily realized by docking in a network port or the same local area network,UDisc playback, scene switching, power sequencer, power amplifier switching and other functions.
Another feature of this product is that it does not have an operating system, is purely hardware-driven display, and can run on power, and has fast computing speed; compared with traditional Android screens, it has never crashed performance, and you can operate the panel when you call, without the need for system startup.1Minutes or tens of seconds; the cost is lower than that of the system screen, and the consistent design concept of intelligence and convenience is what we pursue.
Technical parameters:
Product type: Touch programmable audio matrix processor control panel
Core processing:CORTEX-M3+high-speedFPGA
size:5.5inch
Resolution:1024*768
Communication interface:RJ45Network port, local area network
Operating temperature:-20°~ +70°
Relative humidity:10%—90%@40℃, no condensation cream
Effective display size of the screen(long×wide): 108.0×65mm
Product size(long×wide×high): 146×92×28mm(High without bottom box)
Opening size:150mm(long)×96mm(wide)×32mm(high)
Net weight of product:0.5kg
