1. has3Large-scale independent intellectual property rights, including: appearance patents, utility model patents, and software copyrights;
2. Comprehensive matrix mixing capabilities,24bit/96KHzSampling frequency, high performanceA/D D/Aconverter and32-bitfloating point DSPProcessor;
3. High-precision input sensitivity adjustment, total17step length3dB, maximum input gain51dB;
4.Built-in feedback suppression device, echo cancellation device, environmental noise suppression device;
5. Software interface support: Chinese, English, traditional (other languages can be customized), and the supporting software has dozens of audio processor modules:31Segment equalizer,5Segment parametric equalizers, compressors, limiters, expanders, frequency dividers, tuning pushrods, delayers, dumb controllers, automatic mixers, feedback, matrices, signal indicator tables and signal generators, etc.;
6.Input and output equalizer: Input and output equalizer type has5segment parameter equalization,8segment parameter equalization,10segment parameter equalization,12Segment parametric equalization (parametric equalization can be selected from high-pass, low-pass, overhead, and low-frame),15Paragraph diagram is balanced,31Segment diagram balance can be selected by users according to system debugging needs;
7.The audio matrix processor can realize remote control and remotely debug and maintain equipment in real time, solving the problem of long response time for product application debugging and after-sales maintenance.
8.Convenient and quick web control: Built-in web control port,Windows、Android、iOSIt can be operated quickly on other platforms;
9.Equipment control: Available throughIPAD, smartphones,PCWireless control of the mode switching of the audio processor and the switch of the internal processing unit, and can remotely control the power amplifier and power sequencer in this brand to turn on and off;
10.Software Download: Built-in processorPCDebugging software, you can log in directlyIPAddress Download operating software.
Technical parameters:
Software interface support: Chinese, English, traditional (customizable in other languages)
DSPProcessing chip:Ti 450MHz DSP
Analog input channel:12Road, Phoenix Terminal
Analog output channel:8Road, Phoenix Terminal
Support scene preset saving:100group(userPC)
Ethernet controlIPLogin software download: Yes
RS485Number of serial ports: 1a
RJ45Port:3road
USBQuantity: 1, can support recording and broadcasting
AES/EBUNumber of channels: 3stereo inputs+4Channel stereo output
Quantified bits:24bit
Sampling rate:96KHz
Frequency response:20~20KHz
Maximum analog gain -51dB
phantom power 48V
input-output quantization 96KHz/24bit
A/Ddynamic range 120dB
input common-mode rejection 80 dB @ +24dBu @60Hz
input impedance 20kΩ balance，10kΩ unbalance
maximum input 24dBu
D/Adynamic range 120dB
channel isolation 100dB
AES/EBUBalanced (differential) connection 110Ω
AES/EBUlevel range 0.5-5V VPP
AES/EBUjitter ±20nS
frequency response(20～20kHz) ±0.2dB
total harmonic distortion(THD+N) 0.002% @1kHz，+4dBu
output impedance 100 Ω balance，50 unbalance
maximum output 24dBu
operating temperature 0~40℃
Working power supply:AC110V-220V,50Hz/60Hz
size(widexdeepxhigh) ：485×270×45mm
Product weight:3kg
