4Circuit balanced input, using Cannon interface,8Circuit balanced output, using Cannon interface;
Chinese and English bilingual software, humanized and intuitive operation interface;
24bit/96KHzSampling frequency, high performanceA/D D/Aconverter and32-bitfloating point DSPProcessor;
The device has an information display screen that can display the device name, scene name, debugging parameters, etc.;
inputDSPThe supporting software has a variety of audio processor modules: noise gate, input parametric equalizer, matrix mixer, output parametric equalizer, frequency divider, delay, compressor, signal generator, etc.;
30Each user preset,1Each factory preset, the whole machine parameters and a single preset file can be stored and recalled separately.PCThe operating software is connected with one-click, making user operations more convenient and fast;
canUSBandRS232Port for control, can accept external third-party equipment control (central control), the software hasRS-232Communication protocol control code.
All types of high-cut, low-cut filters, and frequency dividers can be selected:Butterworth、Linkwitz-Riley、Bessel, the slope is -6dB/Octto-48dB/OctOptional;
The threshold value, ratio, start time and recovery time of all compressors are continuously adjustable, and the threshold value, start time and recovery time of the noise gate are continuously adjustable;
All input and output parameters can be adjusted in conjunction;
Technical parameters:
Software interface support: Chinese, English (customizable in other languages)
Analog input channel:4Lu, Makannon
Analog output channel:8Lu, three-needle male Kanong
Equipment Archive:300, you can set one as the boot file at will
RS232Number of serial ports: 1a
frequency response(20～20kHz) ±0.2dB
total harmonic distortion(THD+N) 0.002% @1kHz，+4dBu
Output impedance:110 Ω balance，50 unbalance
Maximum output:16dBu
Operating temperature:-20~80℃
Working power supply:AC110V-220V,50Hz/60Hz
size(widexdeepxhigh) ：483×280×44mm
Product weight:3.5kg
