LA-1202 single12Linear array slightly
product introduction
LAThe series of linear array slightly is a high-precision linear array speaker system. It has a large dynamic capacity and can provide clean, continuous and accurate high-quality sound. It applies phase correction and patented linear horn technology to faithfully restore spectrum signals within the specified range;LAThe series of slightly adopts a built-in frequency division method. After rigorous debugging, it can fully and effectively utilize the characteristics of slightly itself. The box is made of high-strength birch plywood, and the surface is sprayed with special materials. The speaker is equipped with a precision aluminum alloy hanging system. The connection angle between the slightly and slightly can be adjusted through lifting parts. The latest ergonomics and mechanical design make the entire system installed quickly and ensure safety.
product features
● High-quality unit configuration, patented linear horn, beautiful sound quality, accurate projection
● Small size and light weight for easy handling and fixed installation
● Convenient and simple hanging method, easy and quick installation
product application
Sports venues, indoor and outdoor performances, theaters, concert halls, performing arts centers, conference centers, multi-purpose halls, lecture halls, auditoriums, theme parks and other places that require high-quality sound reinforcement and loud sound delivery over long distances.
LA-1202single12Inch full-frequency linear array slightly
Technical parameters:
Type: Full-range linear slightly (two-frequency)
Box composition: high-strength birch plywood, polyurea spraying process
Frequency response:50Hz-20KHz(-3dB)
Sensitivity:103dB 1.0W/1m
Sound pressure level:130dB (continuous).136dB(Peak)
Nominal impedance:8 Ω
Rated power:800W
Peak power:3200W
Unit configuration:LOW:1×12"European custom neodymium magnetic unit (Φ100mmvoice coil)
HI:1×1.4"（Φ65mmEuropean custom neodymium magnetic unit)
Coverage angle:100°(H), the vertical angle is adjusted according to the lifting parts of the slightly,(0、2、4、6、8、10、12、14、16°) Multiple angles adjustable
Product size:722(wide)×465(deep)×353(Former high)×243(Later high)mm
Weight:29kg
Connecting socket:2 Neutrik NL4MP
Hanging hardware: aluminum alloy hanging piece
TType hanger size:700(wide)×736(deep)×50(high)×30(thick)mm
LA-1801single18inch ultra-low linear bass slightly
Technical parameters:
Type: Linear bass slightly
Box composition: high-strength birch plywood, polyurea spraying process
Frequency response:35Hz-400Hz(-3dB)
Sensitivity:101dB 1.0W/1m
Sound pressure level:128dB (continuous).134dB(Peak)
Nominal impedance:8 Ω
Rated power:800W
Peak power:3200W
Unit configuration:LOW:1×18"European custom neodymium magnetic unit (Φ100mmvoice coil)
Coverage angle:100°（H）×30°（V）
Product size:722(wide)×650(deep)×480highmm
Weight:45.8kg
Connecting socket:2 Neutrik NL4MP
Hanging hardware: aluminum alloy hanging piece
TType hanger size:700(wide)×736(deep)×50(high)×30(thick)mm
JD-1202Linear slightlyTtype trapeze
It is made of high-strength metal materials for quick and firm installation.
Scope of application:LA-1202withLA-1801hoisting and use,1Group slightly selection1Pay.
