product introduction
inSONIC PRO® AUDIOIn the world, you can feel the future now,KThe series of slightly starts from a humanized design. The sound is just like its appearance. Every detail is naturally and freely without dragging water. The timbre is transparent, and the sense of space and sound quality are excellent. Its handsome appearance and excellent sound quality are suitable for any occasion. In response to the increasing pursuit of effects in China's professional audio market,SONIC PRO® AUDIOForward-looking thinking and insight once again giveKThe configuration of the series of slightly is upgraded, designed and adjusted. The tweeter voice coil upgrade uses imported voice coils to improve the sound expression of slightly, so that this series of slightly can adapt to the needs of more sound reinforcement occasions and faithfully restore sound.
KThe series of slightly has a wealth of hanging and angle adjustment in fixed installation and mobile applications, and has a single speaker at the bottom of the slightly.35mmThe bracket hole seat. box body is15mmIt is composed of high-density board and the surface is made of wear-resistant black dotted waterproof and environmentally friendly water-based paint. Two handles embedded flush with the box are installed on both sides of the slightly for easy handling. The two rear wiring boards are connected in parallelNL4MPThe core socket is easy to connect. The black internally covered acoustically transparent acoustic sponge and perforated iron mesh protect the slightly unit. The surface mesh is fixed with internal hexagonal plane screws. The overall appearance is beautiful and elegant.
product application
Theater, bar, club,KTV, gymnasiums, conferences, mobile performances, multi-functional applications, etc.
Type: Full range slightly
Frequency response:40Hz－20KHz(-3dB)
Sensitivity:106dB 1.0W/1m
Sound pressure level:135dB(Continuous).141dB(Peak)
Nominal impedance:4 Ω
Rated power:1000W
Peak power:4000W
Unit configuration:LOW:2×15""（Φ75mmImported voice coil)
HI:1×1.4""（Φ75mmImported voice coil)
Coverage angle:90°（H）×60°（V）
Product size:505(wide) ×473(deep) ×1169(high) mm
Weight:47.19kg
Connecting socket:21 professional slightly socket with chamfered rear bottom strip21 moving roller
Hanging hardware:M8 Rigging point
